A connected component of approximately-vertical, coplanar mesh faces. More...
#include <create_windows.hpp>
Public Attributes | |
| Eigen::Vector4d | plane |
| Hessian normal form [a,b,c,d]: ax+by+cz+d=0. | |
| Eigen::Vector3d | centroid |
| Area-weighted centroid of component faces. | |
| Eigen::Vector3d | normal |
| Unit outward normal (approximately horizontal). | |
| std::vector< std::vector< Eigen::Vector3d > > | boundary_loops |
| Boundary loops ordered by half-edge traversal (outer loop first, then holes) Each loop is a sequence of vertices forming a closed polygon. | |
| std::vector< int > | face_indices |
| Mesh face indices in this component. | |
Detailed Description
A connected component of approximately-vertical, coplanar mesh faces.
Definition at line 19 of file create_windows.hpp.
Member Data Documentation
◆ boundary_loops
| std::vector<std::vector<Eigen::Vector3d> > reusex::geometry::WallCandidate::boundary_loops |
Boundary loops ordered by half-edge traversal (outer loop first, then holes) Each loop is a sequence of vertices forming a closed polygon.
First loop (boundary_loops[0]) is the outer boundary. Additional loops represent holes (e.g., embedded windows/doors).
Definition at line 28 of file create_windows.hpp.
◆ centroid
| Eigen::Vector3d reusex::geometry::WallCandidate::centroid |
Area-weighted centroid of component faces.
Definition at line 21 of file create_windows.hpp.
◆ face_indices
| std::vector<int> reusex::geometry::WallCandidate::face_indices |
Mesh face indices in this component.
Definition at line 30 of file create_windows.hpp.
◆ normal
| Eigen::Vector3d reusex::geometry::WallCandidate::normal |
Unit outward normal (approximately horizontal).
Definition at line 22 of file create_windows.hpp.
◆ plane
| Eigen::Vector4d reusex::geometry::WallCandidate::plane |
Hessian normal form [a,b,c,d]: ax+by+cz+d=0.
Definition at line 20 of file create_windows.hpp.
The documentation for this struct was generated from the following file:
- libs/reusex/include/geometry/create_windows.hpp
